FireFly Sensor Node

$296.93

The FireFly sensor node is a wireless sensor and communication module with a rechargeable battery in a robust housing. The sensor configuration can be assembled as desired, with options to detect temperature, relative humidity, derived PAR, barometric pressure, and GPS location. The FireFly node also acts as a communication hub, connecting to a variety of external sensors and actuators via an M12 connector and uploading external sensor data to the InSight platform. T, rH, PAR, GPS, and P configurations incur additional costs.

Temperature Sensor

Range:
-15° to 65°C (+5° to +149°F)

Accuracy:
±0.5°C from -15° to +65°C (±0.9°F from +5° to +149°F)

Resolution:
0.01°C (0.018°F)

Relative Humidity Sensor

Range:
1% to 90% RH (non-condensing)

Accuracy:
±1.5% from 20% to 90% typical to a maximum of ±2.5% below 20% and above 90%

Resolution:
0.01%

PAR Sensor

Accuracy:
±5% (typical for direct sunlight)

Barometric Pressure Sensor

Range:
0 to 500 kPa (0 to 147.65 inHg)

Accuracy:
±0.5 kPa (0.15 inHg)

Resolution:
0.01 kPa (0.003 inHg)

FireFly Node

Power Source:
2 rechargeable 1.5 Volt batteries

Battery Life:
> 12 months, depending on sampling intervals

Logging Rate:
5 minutes minimal

LoRa Frequencies:
868 MHz (EU); 915 MHz (USA; Australia, Mexico)

GPS Accuracy:
±5 m (± 16.5 ft) radius

Size:
L x W x H = 3.5 x 4.0 x 11.0 cm (1.4 x 1.6 x 4.3 in)

Weight:
127 g (4.5 oz)
